Becker Rotary vane pumps, oil-free

       Becker brand is worldwide a synonym for precisely dosed, smooth industrial processes in many industrial sectors. For application areas with high requirements, as they are common for example in the electronics industries, Gebr. Becker GmbH now offers a new vacuum pump product line: the Series X.

With this special development [suitable for the application], Becker extends its popular VT product range by the compact models VX 4.10 to VX 4.40.

Equipped with completely newly developed vanes, these oil-free VX rotary vane pumps distinguish themselves by high abrasion resistance and with that extremely long service lives. And since no dust develops where there is virtually no wear, the devices of the Series X are perfectly suited for precision processes under clean room conditions.

The latest innovation branded by Becker is outstanding not only because of its 100 percent oil-free operation, excellent degree of efficiency and low power consumption. In the area of sensitive vacuum, Series X also guarantees precise low-pulsation air conduction.

And to top that, Becker offers for the first time full warranty of at least 20,000 maintenance-free operating hours for this innovation - a guarantee for top technology with the following advantages:

• quick, clean, quiet
• oil-free
• vibration stable
• wear resistant
• energy saving
• long-life reliable

An additional reliability plus is the on-site service by Becker in case of need. Exchange installations and the downtimes associated with that are no longer an issue anymore.

type

max. suction air rate
[m³/h] 50/60Hz

max. vacuum
[mbar abs.] 50/60Hz

max. vacuum
[mbar rel.] 50/60Hz

max. motor capacity
[KW] 50/60Hz

VT 4.2

1,9/2,3

400/400

-600/-600

0,09/0,105

VT 4.4

4,1/4,7

150/150

-850/-850

0,18/0,21

VT 4.8

8/9,3

150/150

-850/-850

0,35/0,42

VT 4.10

10/12

150/150

-850/-850

0,37/0,45

VX 4.10

10/12

100/100

-900/-900

0,37/0,45

VT 4.16

16/19

150/150

-850/-850

0,55/0,77

VX 4.16

16/19

100/100

-900/-900

0,55/0,77

VT 4.25

25/30

150/150

-850/-850

0,75/0,90

VX 4.25

25/30

100/100

-900/-900

0,75/0,90

VT 4.40

40/48

150/150

-850/-850

1,25/1,50

VX 4.40

40/48

100/100

-900/-900

1,25/1,50

KVT 3.60

55/66

100/100

-900/-900

2,40/3,00

KVT 3.80

67/78,5

100/100

-900/-900

2,40/3,00

KVT 3.100

98/112

100/100

-900/-900

3,00/3,50

KVT 3.140

132/154

100/200

-900/-800

4,00/4,80

VTLF 2.200

178/218

200/200

-800/-800

4,00/4,80

VTLF 2.250

244/286

200/200

-800/-800

5,50/6,40

VTLF 360

350/-

250/-

-750/-

11,0/-

VTLF 400

372/450

200/200

-800/-800

11,0/13,2

VTLF 500

498/600

250/250

-750/-750

15,0/18,0
